Instruction Processing Time
Appendix1 Instruction Processing Time
Instruction
Condition
(Device)
Number
of Steps
Processing
Time (
µs)
LD
1
2.6
LDI
1
2.7
AND
1
2.8
ANI
1
2.8
OR
1
2.7
ORI
1
2.8
ORB
1
2.0
ANB
1
2.0
MPS
1
1.9
MRD
1
1.9
MPP
1
2.0
MC
5
3.7
MCR
3
2.4
NOP
1
2.1
NOPLF
1
2.1
END
1
1.3
PLS
3
3.6
PLF
3
3.5
SFT
3
3.6
SFTP
3
4.1
OUT
Y,M
1
2.5
Special M
3
3.2
T
1
2.5
C
1
2.6
SET
Y,M
1
2.5
Special M
3
3.1
RST
Y,M
1
2.6
Special M
3
3.3
T
3
3.8
C
3
3.8
D
3
3.2
MOV
5
7.7
MOVP
5
8.5
WAND
5
10.3
WANDP
5
10.7
WAND
7
10.1
WANDP
7
10.7
WOR
5
10.3
WORP
5
10.7
WOR
7
10.2
WORP
7
10.6
WXOR
5
10.4
WXORP
5
10.8
WXOR
7
10.3
WXORP
7
10.7
WXNR
5
10.5
WXNRP
5
10.9
WXNR
7
10.3
WXNRP
7
10.7
NEG
3
7.7
NEGP
3
8.1
LD=
5
7.7
LD=
7
8.3
LD<>
5
7.8
LD<>
7
8.3
LD>
5
7.7
LD>
7
8.3
LD<=
5
7.8
LD<=
7
8.3
LD<
5
7.8
LD<
7
8.3
LD>=
5
7.9
LD>=
7
8.3
AND=
5
7.3
AND=
7
7.5
AND<>
5
7.4
AND<>
7
7.5
AND>
5
7.4
AND>
7
7.5
AND<=
5
7.5
AND<=
7
7.7
AND<
5
7.4
AND<
7
7.7
AND>=
5
7.5
AND>=
7
7.7
OR=
5
7.4
OR=
7
8.1
OR<>
5
7.5
Instruction
Condition
(Device)
Number
of Steps
Processing
Time (
µs)
