Chapter 4: Site Selection and Deployment Guidelines

Figure 4-14

Finish wrapping the tape around the antenna base
























If using an antenna with vent holes above the antenna base (e.g. the 2.4 GHz downtilt antenna) do not
tape over the vent holes.



Figure 4-15

Repeat this on the other antenna
