Appendix A:

Figure 9-25

Front View of the Australian Power Connector Plug with Opened Sides

Figure 9-26

Side View of the Australian Power Connector Plug with Opened Sides

Access Screw

Access Screw

3.

Place the plug down with its contents open and facing up. The Strain Relief section of the plug should
be on the left hand side, as shown in the graphic below.

Figure 9-27

Inside View of the Australian Power Connector Plug

GROUND

Access Screw

LINE

NEUTRAL

Strain Relief Section (2 screws)

9-21
