Figure 9-30, Figure 9-31 – Motorola 2.1 User Manual
Page 125
Appendix A:
Figure 9-30
Correct Wire Positioning on Either Side of Screw Well
Screw Well
Strain Relief Bar
4.
Press the wire base against the plug so that the wires are pulled through and the cable fits snugly
at the base of the plug. Tighten the two Strain Relief Screws to lock the cable in place. See the
graphic below for an example of the desired effect.
Figure 9-31
Correct Position of the Cable Below the Strain Relief Bar
Screw Well
Strain Relief
Screws
5.
Attach the cable wires to the terminal plug in the following way.
9-24
