114
Chapter 7: Adding or Replacing Components
www.gateway.com
7
Slide the new system board into the keyhole slots and lock it into place
with the thumbscrew.
8
Reconnect the power and data cables using your notes from Step 4. For
more information, see the system board documentation.
9
Reinstall the add-in cards by following the instructions in “Adding or
replacing add-in cards” on page 103.
10
Close the case by following the instructions in “Closing the case” on
page 95.
Important The new system board must have special standoffs
(
pem studs) mounted on the bottom of the board. If
necessary, use the standoffs from the original system
board.
