G0486/G0487 Wide Belt Sander -67-
Air System Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
101 PH29339101 FILTER CUP 122 PH29339122 AIR SWITCH 1/8"
102 PH29339102 PRESSURE REGULATOR W/GAUGE 123 PH29339123 CONNECTOR 1/4N X 1/8T
103 PH29339103 BRONZE CONNECTOR 5/16N X 1/4T 124 PH29339124 CONNECTOR 1/4N X 1/8T 90º
104 PH29339104 8 X 900MM FLEXIBLE HOSE 125 P04869125 BUFFER 1/8"(BRONZE)
105 PH29339105 AIR VALVE 1/4" 126 P04869126 DIAPHRAGM ASSEMBLY
106 PH29339106 ELBOW 1/4T X 1/4T 90º 127 PH29339127 CONNECTOR 5/16N X 1/8T 90º
107 PS22 PHLP HD SCR 10-24 X 5/8 128 PH29339128 8 X 900MM FLEXIBLE HOSE
108 PH29339108 ELBOW 5/16N X 1/8T 90º 129 PH29339129 8 X 1650MM FLEXIBLE HOSE
109 PH29339109 SOLENOID VALVE 130 P04869130 6MM FLEXIBLE HOSE
110 PH29339110 T-FITTING 5/16N X 5/16N X 1/8T 131 P04869131 6 X 1700MM FLEXIBLE HOSE (G0486)
111 PH29339111 PLASTIC CONNECTOR 1/4N X 1/4T 131 P04879131 6 X 1800MM FLEXIBLE HOSE (G0487)
112 PH29339112 MANIFOLD 1/4N 132 P04869132 6 X 800MM FLEXIBLE HOSE (G0486)
113 P04869113 PLASTIC CONNECTOR 5/16N X 1/4T 132 P04879132 6 X 950MM FLEXIBLE HOSE (G0487)
114 P04869114 BRONZE ELBOW 1/4T X 1/8T-90 133 PH29339133 6 X 600MM FLEXIBLE HOSE
115 PH29339115 PLASTIC CONNECTOR 1/4N X 1/8T 90º 134A PH29339134 6 X 650MM FLEXIBLE HOSE FRONT
116 PH29339116 PLASTIC CONNECTOR 1/4N X 1/8T 90º 134B PH29339134 6 X 300MM FLEXIBLE HOSE REAR
117 PH29339117 THROTTLE VALVE 1/8" 135 PH29339135 6 X 700MM FLEXIBLE HOSE
118 P04869118 PLASTIC CONNECTOR 1/4N X 1/8T 136 PH29339136 6 X 350MM FLEXIBLE HOSE
119 P04869119 BRONZE CONNECTOR 1/4N X 1/4 137 PH29339137 6 X 700MM FLEXIBLE HOSE
120 P04869120 PLASTIC CONNECTOR 1/4N X 3/8T 138 P04869138 6 X 1500MM FLEXIBLE HOSE (G0486)
121 PH29339121 PLASTIC CONNECTOR 1/4N X 1/8T 138 P04879138 6 X 1700MM FLEXIBLE HOSE (G0487)
