G0486/G0487 Wide Belt Sander
-51-
Sanding Motor System Parts List
REF PART #
DESCRIPTION
REF PART #
DESCRIPTION
101
P05811101
MACHINE FRAME (G0486)
127
P04861127
LIMIT SWITCH PLATE
101
P04871101
MACHINE FRAME (G0487)
128
PB19
HEX BOLT 1/4-20 X 1/2
102
P05811102
MOTOR BASE (G0486)
129
PW06
FLAT WASHER 1/4
102
P04871102
MOTOR BASE (G0487)
132
PFH12M
FLAT HD SCR M6-1 X 25
103
P05811103
MOTOR BASE HINGE
133
PLW02
LOCK WASHER 1/4
104
PN06
HEX NUT 1/2-12
201
P04861201
IDLE WHEEL ADJ. BRACKET
105
PH29331105
MOTOR BASE ADJUSTMENT ROD
202
PLW10
LOCK WASHER 3/4
106
PLW07
LOCK WASHER 1/2
203
PN06
HEX NUT 1/2-12
107
PB41
HEX BOLT 1/2-12 X 1-1/2
204
PW13
FLAT WASHER 3/4
108
PW01
FLAT WASHER 1/2
205
PB84
HEX BOLT 3/8-16 X 3-1/2
109
P04861109
MOTOR 25 HP 220/440V 3PH (G0486)
206
PN08
HEX NUT 3/8-16
109
P04871109
MOTOR 30HP 220/440V 3PH (G0487)
208
P04861208
IDLE WHEEL SHAFT
109-1 P04861109-1 MOTOR FAN (G0486)
209
P6305
BALL BEARING 6305ZZ
109-1 P04871109-1 MOTOR FAN (G0487)
210
P04861210
PULLEY
109-2 P04861109-2 MOTOR FAN COVER (G0486)
211
P6206
BEARING 6206ZZ
109-2 P04871109-2 MOTOR FAN COVER (G0487)
212
PR11M
EXT RETAINING RING 25MM
110
P05811110
PULLEY
213
PVA40
V-BELT A-40 4L400
111
PSB11
CAP SCREW 5/16-18 X 1-1/4
301
P04861301
BRAKE BRACKET
112
PLW01
LOCK WASHER 5/16
301-1 P04861301-1 BRAKE BRACKET FRONT GUARD
113
PH29331113
KEY 12 X 8 X 105
302-1 P04861302-1 BRAKE LINING
114
PB03
HEX BOLT 5/16 -18 X 1
302-2 P04861302-2 BRAKE LINING
115
PLW01
LOCK WASHER 5/16
303
P04861303
BRAKE ARBOR
116
PH29331116
ROTOR
304
P04861304
BRAKE COMPRESSION SPRING
117
PVB76
V-BELT B-76 5L760
305
P04861305
BRAKE INSIDE PIECE
118
P05811118
PULLEY BUSHING
306
PFH04
FLAT HD SCR 1/4-20 X 5/8
119
PVA50
V-BELT A-50 4L500
307
P04861307
BRAKE PIN
121
P04861121
BRAKE BRACKET
308
PSB31
CAP SCREW 10-24 X 5/8
122
PW02
FLAT WASHER 3/8
310
PLW04
LOCK WASHER 3/8
123
PB21
HEX BOLT 3/8-16 X 3/4
311
PN08
HEX NUT 3/8-16
124
P04861124
FLAT HEAD NUT
312
PSB01
CAP SCREW 1/4-20 X 5/8
125
PSB05
CAP SCREW 1/4-20 X 3/4
313
P04861313
BRAKE GASKET
126
P04861126
LIMIT SWITCH
314
P04861314
BRAKE ASSEMBLY
