G0486/G0487 Wide Belt Sander -53-
Table Lift System Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
101 P04862101 ELEVATION SCREW 319 PB07 HEX BOLT 5/16-18 X 3/4
102 PB03 HEX BOLT 5/16-18 X 1 320 PSS07 SET SCREW 1/4-20 X 1/2
103 PW07 FLAT WASHER 5/16 321 P04862321 HAND WHEEL
104 PLW01 LOCK WASHER 5/16 322 P04862322 MOTOR BASE
105 PLW01 LOCK WASHER 5/16 323 PB31 HEX BOLT 1/4-20 X 1
106 PB18 HEX BOLT 3/8-16 X 1 324 PLW02 LOCK WASHER 1/4
107 P04862107 ELEVATION SLIDE 325 P04862325 MOTOR BASE ADJ. ROD
108 P04862108 DUST BOOT 326 PW01 FLAT WASHER 1/2
109 PB07 HEX BOLT 5/16-18 X 3/4 327 PN06 HEX NUT 1/2-12
110 PLW01 LOCK WASHER 5/16 328 PLW07 LOCK WASHER 1/2
111 P05812111 CHAIN (G0486) 329 PW06 FLAT WASHER 1/4
111 P04872111 CHAIN (G0487) 331 PH29332331 MOTOR 1/4HP 220V/440V 3PH
201 P04862201 NUT HOUSING 331-1 PH29332331-1 MOTOR FAN COVER
202 P04862202 NUT 331-2 PH29332331-2 MOTOR FAN
203 P51107 THRUST BEARING 51107 332 PN05 HEX NUT 1/4-20
204 PR12M EXT RETAINING RING 35MM 333 PB89 HEX BOLT 1/2-12 X 4-1/2
206 P04862206 SPROCKET WHEEL 334 P04862334 PROXIMITY SWITCH PLATE
207 P04862207 NUT HOUSING ASSEMBLY 335 PB19 HEX BOLT 1/4-20 X 1/2
301 P04862301 ELEVATION GEAR BOX 336 P04862336 PROXIMITY SWITCH
302 P04862302 WORM GEAR 337 P04862337 SPECIAL SCREW M3-.5 X 35
303 P6005 BALL BEARING 6005ZZ 338 PN07M HEX NUT M3-.5
304 P04862304 BEARING CAP 339 PK14 KEY 5/16 X 5/16 X 3/4
305 PSB05 CAP SCREW 1/4-20 X 3/4 340 PK48M KEY 4 X 4 X 20
306 P04862306 WORM SHAFT 341 PK37M KEY 4 X 4 X 16
307 P6002 BALL BEARING 6002ZZ 342 P04862342 ELEVATION GEAR BOX ASSY
308 P04862308 BEARING CAP 401 P04862401 SPROCKET WHEEL ADJUSTOR
309 PSB33 CAP SCREW 10-24 X 3/4 402 P04862402 SPROCKET WHEEL SHAFT
310 P04862310 BEARING CAP 403 P6003 BALL BEARING 6003ZZ
311 PSB01 CAP SCREW 1/4-20 X 5/8 404 P04862404 ADJUSTMENT SPROCKET
312 P04862312 SPROCKET WHEEL 405 P04862405 SPROCKET ADJUSTMENT ROD
313 PSS08 SET SCREW 5/16-18 X 1/2 406 PW02 FLAT WASHER 3/8
314 P04862314 PULLEY 407 PN08 HEX NUT 3/8-16
315 PVA36 V-BELT A-36 4L360 408 PN02 HEX NUT 5/16-18
316 P04862316 PULLEY 409 PLW01 LOCK WASHER 5/16
317 PSS07 SET SCREW 1/4-20 X 1/2 410 PB07 HEX BOLT 5/16-18 X 3/4
318 PLW01 LOCK WASHER 5/16 411 P04862411 SPROCKET ASSEMBLY
