Grizzly G0486/G0487 User Manual
Page 45
G0486/G0487 Wide Belt Sander
-43-
Wiring Box Components
(G0486 220V/440V, G0487 440V)
Conveyor Motor
Contactor
Emergency Brake
Contactor
UP/DOWN Table Motor
Contactors
Conveyor Motor
Overload Relay
220V Three-
Phase Power
Supply
Junction Block
Sanding Motor
Overload Relay
Fuses
Transformer
Sanding Motor
Start Delay
Sanding Motor
Contactor
Amp Meter
Current Sensor
