G0486/G0487 Wide Belt Sander -57-
Feed, Drum, and Pressure Roller Parts List
REF PART # DESCRIPTION REF PART # DESCRIPTION
103 P04864103 COMPRESSION SPRING 302 P04864302 MIDDLE PISTON BRACKET
107 PN08 HEX NUT 3/8-16 303 PRP16M ROLL PIN 3 X 24MM
108 PB12 HEX BOLT 5/16-18 X 1-1/4 403 P04864403 LR PISTON BRACKET
109 PLW01 LOCK WASHER 5/16 404 P04864404 REAR DEFLECTOR (G0486)
201 P05814201 PISTON ROLLER SHAFT (G0486) 404 P04874404 REAR DEFLECTOR (G0487)
201 P04874201 PISTON ROLLER SHAFT (G0487) 405 P04864405 RR PISTON BRACKET
202 P05814202 PISTON ROLLER (G0486) 406 P04864406 LF PISTON BRACKET
202 P04874202 PISTON ROLLER (G0487) 407 P04864407 FRONT DEFLECTOR (G0486)
203 P6001 BALL BEARING 6001ZZ 407 P04874407 FRONT DEFLECTOR (G0487)
204 P04864204 SHAFT BEARING COLLAR 408 P04864408 L MIDDLE PISTON BRACKET
205 PSS07 SET SCREW 1/4-20 X 1/2 409 P04864409 MIDDLE DEFLECTOR (G0486)
206 P04864206 PISTON ROLLER ASSEMBLY 409 P04874409 MIDDLE DEFLECTOR (G0487)
301 PH29334301 ADJUSTMENT KNOB
