Cabinet assembly parts list – Grizzly G0486/G0487 User Manual
Page 65
G0486/G0487 Wide Belt Sander
-63-
Cabinet Assembly Parts List
REF PART #
DESCRIPTION
REF PART #
DESCRIPTION
101
P04867101
UPPER FRAME COVER (G0486)
109
P05817109
RIGHT DOOR, LOWER FRAME
101
P04877101
UPPER FRAME COVER (G0487)
109-1 P05817109-1 LEFT DOOR, LOWER FRAME
102
P04867102
DUST PORT 4"
110
PFH03
FLAT HD SCR 1/4-20 X 1/2
103
PS14M
PHLP HD SCR M6-1 X 12
111
P05817111
FRONT PROTECTION PLATE (G0486)
104
P04867104
LEFT ACCESS PANEL
111
P04877111
FRONT PROTECTION PLATE (G0487)
105
P04867105
RIGHT ACCESS PANEL
112
PW06
FLAT WASHER 1/4
106
P04867106
DOOR LOCK
113
P04867113
FIXING PLATE
107
PB07
HEX BOLT 5/16-18 X 3/4
114
PB02M
HEX BOLT M6-1 X 12
108
PW07
FLAT WASHER 5/16
115
P04867115
HINGE BOLT
