Sanding Drum and Platen Parts List
REF PART #
DESCRIPTION
REF PART #
DESCRIPTION
101
P04865101
BEARING HOUSING
305
PS01
PHLP HD SCR 10-24 X 1/2
102
P05815102
RUBBER ROLLER (G0486)
306
P05815306
GRAPHITE PRESSURE PLATE (G0486)
102
P04875102
RUBBER ROLLER (G0487)
306
P04875306
GRAPHITE PRESSURE PLATE (G0487)
103
P04865103
FASTENING TUBE
307
P04865307
GRAPHITE BRACKET BASE
104
P05275104
CYL. CARTRIDGE BEARING UCC206
308
P04865308
GRAPHITE BRACKET SHAFT (G0486)
105
P04865105
PULLEY
308
P04875308
GRAPHITE BRACKET SHAFT (G0487)
106
PSB11
CAP SCREW 5/16-18 X 1-1/4
309
P04865309
LOCK COLLAR
107
PK11
KEY 5/16 X 5/16 X 1-3/16
310
PSS03
SET SCREW 1/4-20 X 3/8
108
PLW01
LOCK WASHER 5/16
311
PK110
KEY 1/4 X 1/4 X 1
109
P6205
BALL BEARING 6205ZZ
312
P04865312
COMPRESSION SPRING
110
PLW07
LOCK WASHER 1/2
313
P04865313
HOUSING
111
PSB76
CAP SCREW 1/2-12 X 1-1/2
314
P04865314
GRAPHITE BRACKET SHAFT
112
PSB04
CAP SCREW 1/4-20 X 1/2
315
PSB16
CAP SCREW 3/8-16 X 3/4
113
P04865113
BEARING CAP
316
PW02
FLAT WASHER 3/8
114
P04865114
GREASE FITTING W/CAP
317
PW02
FLAT WASHER 3/8
115
P04865115
GREASE FITTING W/CAP
318
P04865318
HANDLE
116
P04865116
PLUG
319
PSS08
SET SCREW 5/16-18 X 1/2
117
P04865117
PULLEY COVER
320
P04865320
ADJUSTMENT RING
118
PS04
PHLP HD SCR 1/4-20 X 1/2
321
PB03
HEX BOLT 5/16-18 X 1
119
P04865119
SPANNER NUT
322
PW07
FLAT WASHER 5/16
201
P04865201
BEARING HOUSING
323
P04865323
HANDLE
202
P05815202
STEEL ROLLER (G0486)
325
P04865325
GRAPHITE BRACKET ADJ. ASSEMBLY
202
P04875202
STEEL ROLLER (G0487)
401
P04865401
BEARING HOUSING
203
P04865203
SPECIAL CAP SCREW M6-.75 X 6
402
P05815402
RUBBER ROLLER (G0486)
204
P05275104
CYL. CARTRIDGE BEARING UCC205
402
P04875402
RUBBER ROLLER (G0487)
205
P04865205
HANDLE
403
P04865403
FASTENING TUBE
206
P04865206
SPECIAL SCREW
404
P05275104
CYL.CARTRIDGE BEARING UCC206
211
P04865211
BEARING BRACKET PAD
405
P04865405
PULLEY
301
P05815301
44" GRAPHITE BRACKET MALE (G0486)
406
PSB11
CAP SCREW 5/16-18 X 1-1/4
301
P04875301
52" GRAPHITE BRACKET MALE (G0487)
407
P04865407
BEARING HOUSING
302
P05815302
44" GRAPHITE BRACKET FML (G0486)
408
P04865408
BEARING BRACKET PAD
302
P04875302
52" GRAPHITE BRACKET FML (G0487)
409
P6206
BEARING 6206ZZ
303
P05810004
44" FELT PLATEN PAD (G0486)
410
P04865410
SPANNER NUT
303
P04875303
52" FELT PLATEN PAD (G0487)
411
P04865411
BEARING CAP
304
P05810005
GRAPHITE 44" X 3.54" (G0486)
417
P04865417
PULLEY COVER
304
P04875304
GRAPHITE 52" X 3.54" (G0487)
