Appendix A: Server Specifications

www.gateway.com

Hardware monitor specifications

Voltage

Fan

ACPI

ACPI compliant

Supports S0, S1, S4, and S5

Hardware
Monitor

On-board LM81 × 1+MAX1617A on SMBus

Main logic board sensors:

■

+2.5V, +3.3V, +5V, +12V, VTT, CPU core

■

System and CPU temperature

■

CPU fan speed measurement and control

Voltage Source

Maximum Value

Minimum Value

VTT

1.312V

1.150V

Vcc 12V

13.187V

10.750V

Vcc 5V

5.486V

4.498V

Vcc 3.3V

3.457V

3.130V

Vcc 2.5V

2.874V

2.444V

CPU Vcore (1.5V)

1.565V

1.367V

Fan

Maximum Value

Minimum Value

CPU fan

N/A

1200 RPM

System fan 2

N/A

1200 RPM
