Chapter 4: Installing Components
www.gateway.com
13
Align the drive’s screw holes with the release latch’s locking tabs.
14
Slide the drive release latch toward the front of the case until the lock icon
is visible.
15
Follow the instructions in the drive’s documentation to connect the drive
cables.
Locking tabs
Drive screw
holes
Lock icon
