Chapter 3. Printronix P300/P600 Emulation
GEK-00029B
70
Dot Patterns
This chart shows the dot patterns for the ASCII characters needed to
cover all dot/void combinations. Characters from 20H to 3FH provide
the same patterns as characters 60H through 7FH. Characters from
00H through 1FH, which are not recognized as line terminators or
plot mode codes, are ignored.
Character
Value
Dots
Character
Value
Dots
@
40H
000000
’
60H
00000X
A
41H
X00000
a
61H
X0000X
B
42H
0X0000
b
62H
0X000X
C
43H
XX0000
c
63H
XX000X
D
44H
00X000
d
64H
00X00X
E
45H
X0X000
e
65H
X0X00X
F
46H
0XX000
f
66H
0XX00X
G
47H
XXX000
g
67H
XXX00X
H
48H
000X00
h
68H
000X0X
I
49H
X00X00
i
69H
X00X0X
J
4AH
0X0X00
j
6AH
0X0X0X
K
4BH
XX0X00
k
6BH
XX0X0X
L
4CH
00XX00
l
6CH
00XX0X
M
4DH
X0XX00
m
6DH
X0XX0X
N
4EH
0XXX00
n
6EH
0XXX0X
O
4FH
XXXX00
o
6FH
XXXX0X
P
50H
0000X0
p
70H
0000XX
Q
51H
X000X0
q
71H
X000XX
R
52H
0X00X0
r
72H
0X00XX
S
53H
XX00X0
s
73H
XX00XX
T
54H
00X0X0
t
74H
00X0XX
U
55H
X0X0X0
u
75H
X0X0XX
V
56H
0XX0X0
v
76H
0XX0XX
W
57H
XXX0X0
w
77H
XXX0XX
X
58H
000XX0
x
78H
000XXX
Y
59H
X00XX0
y
79H
X00XXX
Z
5AH
0X0XX0
z
7AH
0X0XXX
[
5BH
XX0XX0
{
7BH
XX0XXX
\
5CH
00XXX0
|
7CH
00XXXX
]
5DH
X0XXX0
}
7DH
X0XXXX
^
5EH
0XXXX0
~
7EH
0XXXXX
_
5FH
XXXXX0
?
3FH
XXXXXX
