GEK-00029B 5000 Series Programmer’s Manual 37
This chart shows the dot patterns for the ASCII characters needed to
cover all dot/void combinations. Other valid characters (although
they are repeat patterns of the characters in the chart) are 20H-3FH.
Character Value Dots Character Value Dots
@ 40H 000000 ’ 60H 00000X
A 41H X00000 a 61H X0000X
B 42H 0X0000 b 62H 0X000X
C 43H XX0000 c 63H XX000X
D 44H 00X000 d 64H 00X00X
E 45H X0X000 e 65H X0X00X
F 46H 0XX000 f 66H 0XX00X
G 47H XXX000 g 67H XXX00X
H 48H 000X00 h 68H 000X0X
I 49H X00X00 i 69H X00X0X
J 4AH 0X0X00 j 6AH 0X0X0X
K 4BH XX0X00 k 6BH XX0X0X
L 4CH 00XX00 l 6CH 00XX0X
M 4DH X0XX00 m 6DH X0XX0X
N 4EH 0XXX00 n 6EH 0XXX0X
O 4FH XXXX00 o 6FH XXXX0X
P 50H 0000X0 p 70H 0000XX
Q 51H X000X0 q 71H X000XX
R 52H 0X00X0 r 72H 0X00XX
S 53H XX00X0 s 73H XX00XX
T 54H 00X0X0 t 74H 00X0XX
U 55H X0X0X0 u 75H X0X0XX
V 56H 0XX0X0 v 76H 0XX0XX
W 57H XXX0X0 w 77H XXX0XX
X 58H 000XX0 x 78H 000XXX
Y 59H X00XX0 y 79H X00XXX
Z 5AH 0X0XX0 z 7AH 0X0XXX
[ 5BH XX0XX0 { 7BH XX0XXX
\ 5CH 00XXX0 | 7CH 00XXXX
] 5DH X0XXX0 } 7DH X0XXXX
^ 5EH 0XXXX0 ~ 7EH 0XXXXX
_ 5FH XXXXX0 ? 7FH XXXXXX
Legend: X=dot 0=no dot (void)
