Chapter 2. ANSI Emulation
GEK-00029B
48
Bar Code Dimensions
p2
Bar code height in 1/12-inch increments
Minimum:
1=l/12 inch
Maximum:
120=10 inches
Default:
9=9/12 inch (3 / 4 inch)
Human-readable line is not included in height.
p3
Human-readable line
0=Do not print human-readable line
1=Print human-readable line (default)
p4
Narrow bar width, number x 1/120 inch
Default:
2 (2/120 inch, approximately .017 inch)
Range:
2, 4, 6, . . . 126
p5*
Wide bar width, number x 1/120 inch
Default:
6 (6/120 inch, approximately . 050 inch)
Range:
2, 4, 6, . . . 254
p6
Narrow space width, number x 1/120 inch
Default:
2 (2/120 inch, approximately . 017 inch)
Range:
2. 4, 6, . . .126
p7*
Wide space width, number x 1/120 inch
Default:
6 (6/120 Inch. approximately .050 inch)
Range:
2, 4, 6, . . . 254
p8*
Intercharacter space width, number x: 1/120 inch
Default:
2 (2/120 inch, approximately . 017 inch)
Range:
2, 4, 6 . . . 126
* Parameters
bar code styles since they are generated from other parameters.
NOTE
The following dimensions are for barcodes printed at 0 and 180
degrees rotation. Barcodes printed at 90 or 270 degrees rotation
will be compressed by a 6:5 ratio due to the difference in size of
the horizontal and vertical grids.
