GEK-00029A 5000 Series Programmer’s Manual 153
ESC * m n1 n2 Select Graphics Mode: Selects graphics mode m (see table below) for
v1...vn n1 + (n2 x 256) columns. The variables n1 and n2 represent the
number of data bytes to be sent that will be interpreted as graphics.
If the number of graphics columns to be printed causes printing to
exceed the right margin, all data beyond that margin will be ignored.
m Graphics Mode DPI
0 Single-density 60
1 Double-density 120
2 High-speed double-density 120
3 Quadruple-density 240
4 CRT I 120
5 Plotter (1:1) 60
6 CRT II 120
7 Double-density plotter 120
Decimal: 27 42 n1 n2 v1...vn
Hex: 1B 2A n1H n2H v1H...vnH
BASIC: CHR$(27);"*";CHR$(m);CHR$(n1);CHR$(n2);
CHR$(v1);...;CHR$(vn);
ESC ? s n Reassign Graphics Mode: Reassigns the dot density to the graphics
mode specified by ESC K, ESC L, ESC Y, or ESC Z.
s=K, L, Y, or Z
n=dot density (see values below)
n
Horizontal
dpi
Vertical
dpi
0 60 72
1 120 72
2 120 72
3 240 72
4 80 (120) 72
5 72 (60) 72
6 90 (120) 72
7 144 (120) 72
Example:
Normally, when the printer receives the ESC L command, the dot
density is 120 dpi x 72 dpi vertical. By using this command, you can
reassign that density to 60 dpi horizontal x 72 dpi vertical by sending
the following:
CHR$(27);"?";"I";CHR$(0);
NOTE
The emulation converts the values corresponding to n4 through n7
to the ones shown in parenthesis.
