GEK-00029B 5000 Series Programmer’s Manual 19
Housekeeping Sequences
ESC [ CSI (Control Sequence Introducer): This sequence is used to begin
sequences, that generally have multiple parameters.
ESC ] OSC (Operating System Command): This is another special
sequence introducer. Sequences which begin with OSC require the
ST string terminator sequence (ESC \) to end them.
ESC \ ST (String Terminator): Terminates the loading of EVFU tables,
download fonts, and dot graphics strings.
ESC c RIS (Reset to Initial State): Resets the printer to either the standard
state shown below or to the state stored in the customer save area of
memory. The RIS sequence can be disabled by ANSI option strap 3
(see Appendix D, ANSI (4800) or ANSI (4410), option 3).
RIS – Reset to Initial State
Parameter State
Font Style Gothic Draft
Character Size 1X Vertical, 1X Horizontal
Character Pitch 10 cpi
Country Selection USA
Code Page 437
Line Spacing 6 lpi
Partial Line Up Reset
Partial Line Down Reset
Bold Print Inactive
Underline Mode Inactive
Expanded Mode Inactive
Proportional Mode Reset
Horizontal Tab Table Empty
Left Margin None - Column 0
Right Margin None - Maximum
Form Number 7
Page Size 7920 decipoints/ 66 lines/11 inches
Top Margin None
Bottom Margin None
Forms Position Top of form - current position
Vertical Tab Table Empty
Vertical Format Unit Default
Graphics Density 60 H dpi, 72 V dpi, horizontal format
VFU Load In Progress Exit (nothing saved)
Bar Code Mode Inactive
Dot Graphics Inactive
Decimal 27 99:
Hex: 1B 63
BASIC: CHR$(27);"c";
