GENERAL PRINTER OPTIONS DEFINITIONS
I/F Hardware Straps
H Bits
01-32
Function If Enabled If Disabled
01 Prime High = Buffer Clear. Low = Buffer Clear.
02 Interrupt On all Control Codes.
Disabled on all Control Codes, except
LF, VT, FF, CR, DC1 and DC3.
03 DEL Does not cause an Interrupt. Causes an Interrupt.
04 DEL Does not cause Prime. Causes Prime.
05-06 Reserved.
07 Underline character Treated as CR. Printed.
08 PI Lead Causes Interrupt. Does not cause Interrupt.
09 ACK lead
Does not reflect
ONLINE/LOCAL status. 05
must be enabled.
Reflects ONLINE/LOCAL status.
10
Character
conversion to space.
Enabled. (See 41-48.) Disabled.
11 CR Not decoded. Generate an Interrupt.
12 FF Not decoded. Generate an Interrupt.
13 LF Not decoded. Generate an Interrupt.
14 VT Not decoded. Generate an Interrupt.
15 DC3 Not decoded. Generate an Interrupt.
16 DC1 Not decoded. Generate an Interrupt.
17 Busy Does not reflect ACK. Reflects ACK.
18
Busy/Demand per
character.
Enabled. Disabled.
19
Software control of
Busy.
Disabled Enabled.
20 Busy
Does not reflect
(ONLINE/LOCAL) FAULT/PO
status.
Reflects (ONLINE/LOCAL) FAULT/PO
status.
21 Busy
Does not reflect (FAULT)
ONLINE/LOCAL status.
Reflects (FAULT) ONLINE/LOCAL
status.
22 Busy
Does not reflect (PO)
ONLINE/LOCAL/PO status. Reflects (PO) ONLINE/LOCAL/PO
status.
23 ACK Does not reflect PO. Reflects PO.
24 ACK Does not reflect FAULT. Reflects FAULT.
25 Data leads 0-7 are active high. 0-7 are active low.
26 Busy is active High. Low.
27 PI is active High. Low.
28 PI Enabled. Disabled.
29 STB is active High. Low.
30 SELECT is active High. Low.
31 PO is active High. Low.
32 FAULT is active High. Low.
H Bits
33-64
Function If Enabled. If Disabled
33 Demand delay. Disabled. Enabled.
34
35 Delay
Disable Disable None
Disable Enable 1 µsec
Enable Disable 2 µsec
34-35
Set ACK delay from
Strobe.
Enable Enable 3 µsec
36 37 Width
Disable Disable None
Disable Enable 1 µsec
Enable Disable 2 µsec
36-37
Set ACK Pulse
Width.
Enable Enable 3 µsec
38-40 Reserved.
41-48
Used with strap 10 to select space character substitution. 41 corresponds with Bit 1 of the
character code.
49-64 Reserved.
