18–16 MULTILINK ML1600 ETHERNET COMMUNICATIONS SWITCH – INSTRUCTION MANUAL
MEMORY MAPPING CHAPTER 18: MODBUS PROTOCOL
043A Port 18: Number of oversized frames received 0 to 4294967295 1 F9 0
043C Port 18: Number of bad fragments received (<64 bytes) 0 to 4294967295 1 F9 0
043E Port 18: Number of jabber frames received 0 to 4294967295 1 F9 0
0440 Port 18: Number of collisions occurred 0 to 4294967295 1 F9 0
0442 Port 18: Number of late collisions occurred 0 to 4294967295 1 F9 0
0444 Port 18: Number of 64-byte frames received/sent 0 to 4294967295 1 F9 0
0446 Port 18: Number of 65 to 127 byte frames received/sent 0 to 4294967295 1 F9 0
0448 Port 18: Number of 128 to 255 byte frames received/sent 0 to 4294967295 1 F9 0
044A Port 18: Number of 256 to 511 byte frames received/sent 0 to 4294967295 1 F9 0
044C Port 18: Number of 512 to 1023 byte frames received/sent 0 to 4294967295 1 F9 0
044E Port 18: Number of 1023 to maximum byte frames received/sent 0 to 4294967295 1 F9 0
0450 Port 18: Number of MAC error packets 0 to 4294967295 1 F9 0
0452 Port 18: Number of dropped received packets 0 to 4294967295 1 F9 0
0454 Port 18: Number of multicast frames sent 0 to 4294967295 1 F9 0
0456 Port 18: Number of broadcast frames sent 0 to 4294967295 1 F9 0
0458 Port 18: Number of <64 byte fragments with good CRC 0 to 4294967295 1 F9 0
045A Port 19: Number of bytes received 0 to 4294967295 1 F9 0
045C Port 19: Number of bytes sent 0 to 4294967295 1 F9 0
045E Port 19: Number of frames received 0 to 4294967295 1 F9 0
0460 Port 19: Number of frames sent 0 to 4294967295 1 F9 0
0462 Port 19: Total bytes received 0 to 4294967295 1 F9 0
0464 Port 19: Total frames received 0 to 4294967295 1 F9 0
0466 Port 19: Number of broadcast frames received 0 to 4294967295 1 F9 0
0468 Port 19: Number of multicast frames received 0 to 4294967295 1 F9 0
046A Port 19: Number of frames with CRC error 0 to 4294967295 1 F9 0
046C Port 19: Number of oversized frames received 0 to 4294967295 1 F9 0
046E Port 19: Number of bad fragments received (<64 bytes) 0 to 4294967295 1 F9 0
0470 Port 19: Number of jabber frames received 0 to 4294967295 1 F9 0
0472 Port 19: Number of collisions occurred 0 to 4294967295 1 F9 0
0474 Port 19: Number of late collisions occurred 0 to 4294967295 1 F9 0
0476 Port 19: Number of 64-byte frames received/sent 0 to 4294967295 1 F9 0
0478 Port 19: Number of 65 to 127 byte frames received/sent 0 to 4294967295 1 F9 0
047A Port 19: Number of 128 to 255 byte frames received/sent 0 to 4294967295 1 F9 0
047C Port 19: Number of 256 to 511 byte frames received/sent 0 to 4294967295 1 F9 0
047E Port 19: Number of 512 to 1023 byte frames received/sent 0 to 4294967295 1 F9 0
0480 Port 19: Number of 1023 to maximum byte frames received/sent 0 to 4294967295 1 F9 0
0482 Port 19: Number of MAC error packets 0 to 4294967295 1 F9 0
0484 Port 19: Number of dropped received packets 0 to 4294967295 1 F9 0
0486 Port 19: Number of multicast frames sent 0 to 4294967295 1 F9 0
0488 Port 19: Number of broadcast frames sent 0 to 4294967295 1 F9 0
048A Port 19: Number of <64 byte fragments with good CRC 0 to 4294967295 1 F9 0
048C Port 20: Number of bytes received 0 to 4294967295 1 F9 0
048E Port 20: Number of bytes sent 0 to 4294967295 1 F9 0
0490 Port 20: Number of frames received 0 to 4294967295 1 F9 0
0492 Port 20: Number of frames sent 0 to 4294967295 1 F9 0
0494 Port 20: Total bytes received 0 to 4294967295 1 F9 0
Table 18–1: Modbus memory map (Sheet 14 of 21)
Address Description Range Step Format Default
