6–6 MULTILINK ML1600 ETHERNET COMMUNICATIONS SWITCH – INSTRUCTION MANUAL
CONFIGURING PORT SECURITY THROUGH THE COMMAND LINE INTERFACE CHAPTER 6: ACCESS CONSIDERATIONS
Example 6-3 shows how to allow specific MAC address on specific ports. After the MAC
address is specified, the port or specific ports or a range of ports can be queried as shown.
Example 6-4 shows how to remove a MAC address from port security
To set logging on a port, use the following command sequence:
ML1600(port-security)## signal port=11 logandtrap
Port security Signal type set to Log and
Trap on selected port(s)
The examples provided illustrate the necessary commands to setup port security. The
recommended steps to setup security are:
Z Set the ML1600 software to allow port security commands (use the
port-security command).
Z Enable port security (use the enable ps command).
Z Enable learning on the required ports (for example, use the learn
port=11 enable command for port 11).
Z Verify learning is enables and MAC addresses are being learnt on
required ports (use the
show port-security port=11
command).
Z Save the port-security configuration (use the save command).
Z Disable learning on required ports (for example, use the learn
port=11,15 disable command).
Example 6-3: Allowing specific MAC addresses on specific ports
ML1600(port-security)## allow mac=00:c1:00:7f:ec:00 port=9,11,13
Specified MAC address(es) allowed on selected port(s)
ML1600(port-security)## show port-security port=9,11,13
PORT STATE SIGNAL ACTION LEARN COUNT MAC ADDRESS
---- ----- ------ ------ ----- ----- -----------
9 ENABLE LOG NONE ENABLE 6 00:e0:29:2a:f1:bd
00:01:03:e2:27:89
00:07:50:ef:31:40
00:e0:29:22:15:85
00:03:47:ca:ac:45
00:30:48:70:71:23
00:c1:00:7f:ec:00
11 ENABLE NONE NONE ENABLE 0 00:c1:00:7f:ec:00
13 ENABLE NONE NONE DISABLE 0 00:c1:00:7f:ec:00
Example 6-4: Removing MAC addresses from specific ports
ML1600(port-security)## remove mac=00:c1:00:7f:ec:00 port=13
Specified MAC address(es) removedfrom selected
port(s)
ML1600(port-security)## show port-security port=13
PORT STATE SIGNAL ACTION LEARN COUNT MAC ADDRESS
---- ----- ------ ------ ----- ----- -----------
13 ENABLE NONE NONE ENABLE 0 Not Configured
ML1600(port-security)##
