16–12 MULTILINK ML1600 ETHERNET COMMUNICATIONS SWITCH – INSTRUCTION MANUAL
CONFIGURING SNMP WITH ENERVISTA SECURE WEB MANAGEMENT SOFTWARE CHAPTER 16: SNMP
Z When done changing the community strings, click OK.
Multiple managers can be added as shown below.
When adding SNMP manager stations,
Z Click on the Add button on the SNMP menu screen.
Z Make sure that each station can be pinged from the switch by
using the Administration > Ping menu.
Z When done adding stations, click OK.
When adding SNMP trap receivers,
Z Click on the Add button on the SNMP menu screen.
Z Make sure that each station can be pinged from the switch by
using the Administration > Ping menu.
Z Determine which sorts of traps each station will receive, as shown
above.
Z If not sure, select all three types.
Z When done adding trap receivers, click OK.
