18–14
MULTILINK ML1600 ETHERNET COMMUNICATIONS SWITCH – INSTRUCTION MANUAL
MEMORY MAPPING
CHAPTER 18: MODBUS PROTOCOL
0382
Port 14: Number of 256 to 511 byte frames received/sent
0 to 4294967295
1
F9
0
0384
Port 14: Number of 512 to 1023 byte frames received/sent
0 to 4294967295
1
F9
0
0386
Port 14: Number of 1023 to maximum byte frames received/sent 0 to 4294967295
1
F9
0
0388
Port 14: Number of MAC error packets
0 to 4294967295
1
F9
0
038A
Port 14: Number of dropped received packets
0 to 4294967295
1
F9
0
038C
Port 14: Number of multicast frames sent
0 to 4294967295
1
F9
0
038E
Port 14: Number of broadcast frames sent
0 to 4294967295
1
F9
0
0390
Port 14: Number of <64 byte fragments with good CRC
0 to 4294967295
1
F9
0
0392
Port 15: Number of bytes received
0 to 4294967295
1
F9
0
0394
Port 15: Number of bytes sent
0 to 4294967295
1
F9
0
0396
Port 15: Number of frames received
0 to 4294967295
1
F9
0
0398
Port 15: Number of frames sent
0 to 4294967295
1
F9
0
039A
Port 15: Total bytes received
0 to 4294967295
1
F9
0
039C
Port 15: Total frames received
0 to 4294967295
1
F9
0
039E
Port 15: Number of broadcast frames received
0 to 4294967295
1
F9
0
03A0
Port 15: Number of multicast frames received
0 to 4294967295
1
F9
0
03A2
Port 15: Number of frames with CRC error
0 to 4294967295
1
F9
0
03A4
Port 15: Number of oversized frames received
0 to 4294967295
1
F9
0
03A6
Port 15: Number of bad fragments received (<64 bytes)
0 to 4294967295
1
F9
0
03A8
Port 15: Number of jabber frames received
0 to 4294967295
1
F9
0
03AA
Port 15: Number of collisions occurred
0 to 4294967295
1
F9
0
03AC
Port 15: Number of late collisions occurred
0 to 4294967295
1
F9
0
03AE
Port 15: Number of 64-byte frames received/sent
0 to 4294967295
1
F9
0
03B0
Port 15: Number of 65 to 127 byte frames received/sent
0 to 4294967295
1
F9
0
03B2
Port 15: Number of 128 to 255 byte frames received/sent
0 to 4294967295
1
F9
0
03B4
Port 15: Number of 256 to 511 byte frames received/sent
0 to 4294967295
1
F9
0
03B6
Port 15: Number of 512 to 1023 byte frames received/sent
0 to 4294967295
1
F9
0
03B8
Port 15: Number of 1023 to maximum byte frames received/sent 0 to 4294967295
1
F9
0
03BA
Port 15: Number of MAC error packets
0 to 4294967295
1
F9
0
03BC
Port 15: Number of dropped received packets
0 to 4294967295
1
F9
0
03BE
Port 15: Number of multicast frames sent
0 to 4294967295
1
F9
0
03C0
Port 15: Number of broadcast frames sent
0 to 4294967295
1
F9
0
03C2
Port 15: Number of <64 byte fragments with good CRC
0 to 4294967295
1
F9
0
03C4
Port 16: Number of bytes received
0 to 4294967295
1
F9
0
03C6
Port 16: Number of bytes sent
0 to 4294967295
1
F9
0
03C8
Port 16: Number of frames received
0 to 4294967295
1
F9
0
03CA
Port 16: Number of frames sent
0 to 4294967295
1
F9
0
03CC
Port 16: Total bytes received
0 to 4294967295
1
F9
0
03CE
Port 16: Total frames received
0 to 4294967295
1
F9
0
03D0
Port 16: Number of broadcast frames received
0 to 4294967295
1
F9
0
03D2
Port 16: Number of multicast frames received
0 to 4294967295
1
F9
0
03D4
Port 16: Number of frames with CRC error
0 to 4294967295
1
F9
0
03D6
Port 16: Number of oversized frames received
0 to 4294967295
1
F9
0
03D8
Port 16: Number of bad fragments received (<64 bytes)
0 to 4294967295
1
F9
0
03DA
Port 16: Number of jabber frames received
0 to 4294967295
1
F9
0
03DC
Port 16: Number of collisions occurred
0 to 4294967295
1
F9
0
Table 18–1: Modbus memory map (Sheet 12 of 21)
Address
Description
Range
Step
Format
Default
