CHAPTER 13: RAPID SPANNING TREE PROTOCOL
CONFIGURING RSTP THROUGH THE COMMAND LINE INTERFACE
MULTILINK ML1600 ETHERNET COMMUNICATIONS SWITCH – INSTRUCTION MANUAL
13–13
Configuring RSTP (continued)
ML1600(rstp)##
show stp ports
RSTP Port Configuration
--------------------------------------------------------------------------------------
Port#
Type
Priority
Path Cost
State
Des. Bridge
Des. Port
--------------------------------------------------------------------------------------
09
TP(10/100)
128
2000000
No STP
00:09
10
TP(10/100)
128
2000000
Disabled
00:0a
11
TP(10/100)
128
2000000
Disabled
00:0b
12
TP(10/100)
128
2000000
Disabled
00:0c
13
TP(10/100)
100
250000
Forwarding
80:00:00:20:06:25:ed:89
00:0d
14
TP(10/100)
128
2000000
Disabled
00:0e
15
TP(10/100)
128
2000000
Disabled
00:0f
16
TP(10/100)
128
2000000
Disabled
00:10
ML1600(rstp)##
port port=9 status=enable
ML1600(rstp)##
show stp ports
RSTP Port Configuration
--------------------------------------------------------------------------------------
Port#
Type
Priority
Path Cost
State
Des. Bridge
Des. Port
--------------------------------------------------------------------------------------
09
TP(10/100)
128
2000000
Forwarding
80:00:00:20:06:25:ed:89
00:09
10
TP(10/100)
128
2000000
Disabled
00:0a
11
TP(10/100)
128
2000000
Disabled
00:0b
12
TP(10/100)
128
2000000
Disabled
00:0c
13
TP(10/100)
100
250000
Forwarding
80:00:00:20:06:25:ed:89
00:0d
14
TP(10/100)
128
2000000
Disabled
00:0e
15
TP(10/100)
128
2000000
Disabled
00:0f
16
TP(10/100)
128
2000000
Disabled
00:10
ML1600(rstp)##
timers forward-delay=20 hello=5 age=30
Successfully set the bridge time parameters
ML1600(rstp)##
show stp config
RSTP CONFIGURATION
-----------------
Rapid STP/STP Enabled(Global) : YES
RSTP/STP Enabled Ports
: 9,10,11,12,13,14,15,16
Protocol
: Normal RSTP
Bridge ID
: 80:00:00:20:06:25:ed:89
Bridge Priority
: 0
Bridge Forward Delay
: 20
Bridge Hello Time
: 05
Bridge Max Age
: 30
Root Port
: 0
Root Path Cost
: 0
Designated Root
: 80:00:00:20:06:25:ed:89
Designated Root Priority
: 0
Root Bridge Forward Delay
: 20
Root Bridge Hello Time
: 05
Root Bridge Max Age
: 30
Topology Change Count
: 0
Time Since Topology Chg
: 567
ML1600(rstp)##
exit
ML1600#
