CHAPTER 18: MODBUS PROTOCOL MEMORY MAPPING
MULTILINK ML1600 ETHERNET COMMUNICATIONS SWITCH – INSTRUCTION MANUAL 18–9
01B6 Port 5: Number of collisions occurred 0 to 4294967295 1 F9 0
01B8 Port 5: Number of late collisions occurred 0 to 4294967295 1 F9 0
01BA Port 5: Number of 64-byte frames received/sent 0 to 4294967295 1 F9 0
01BC Port 5: Number of 65 to 127 byte frames received/sent 0 to 4294967295 1 F9 0
01BE Port 5: Number of 128 to 255 byte frames received/sent 0 to 4294967295 1 F9 0
01C0 Port 5: Number of 256 to 511 byte frames received/sent 0 to 4294967295 1 F9 0
01C2 Port 5: Number of 512 to 1023 byte frames received/sent 0 to 4294967295 1 F9 0
01C4 Port 5: Number of 1023 to maximum byte frames received/sent 0 to 4294967295 1 F9 0
01C6 Port 5: Number of MAC error packets 0 to 4294967295 1 F9 0
01C8 Port 5: Number of dropped received packets 0 to 4294967295 1 F9 0
01CA Port 5: Number of multicast frames sent 0 to 4294967295 1 F9 0
01CC Port 5: Number of broadcast frames sent 0 to 4294967295 1 F9 0
01CE Port 5: Number of <64 byte fragments with good CRC 0 to 4294967295 1 F9 0
01D0 Port 6: Number of bytes received 0 to 4294967295 1 F9 0
01D2 Port 6: Number of bytes sent 0 to 4294967295 1 F9 0
01D4 Port 6: Number of frames received 0 to 4294967295 1 F9 0
01D6 Port 6: Number of frames sent 0 to 4294967295 1 F9 0
01D8 Port 6: Total bytes received 0 to 4294967295 1 F9 0
01DA Port 6: Total frames received 0 to 4294967295 1 F9 0
01DC Port 6: Number of broadcast frames received 0 to 4294967295 1 F9 0
01DE Port 6: Number of multicast frames received 0 to 4294967295 1 F9 0
01E0 Port 6: Number of frames with CRC error 0 to 4294967295 1 F9 0
01E2 Port 6: Number of oversized frames received 0 to 4294967295 1 F9 0
01E4 Port 6: Number of bad fragments received (<64 bytes) 0 to 4294967295 1 F9 0
01E6 Port 6: Number of jabber frames received 0 to 4294967295 1 F9 0
01E8 Port 6: Number of collisions occurred 0 to 4294967295 1 F9 0
01EA Port 6: Number of late collisions occurred 0 to 4294967295 1 F9 0
01EC Port 6: Number of 64-byte frames received/sent 0 to 4294967295 1 F9 0
01EE Port 6: Number of 65 to 127 byte frames received/sent 0 to 4294967295 1 F9 0
01F0 Port 6: Number of 128 to 255 byte frames received/sent 0 to 4294967295 1 F9 0
01F2 Port 6: Number of 256 to 511 byte frames received/sent 0 to 4294967295 1 F9 0
01F4 Port 6: Number of 512 to 1023 byte frames received/sent 0 to 4294967295 1 F9 0
01F6 Port 6: Number of 1023 to maximum byte frames received/sent 0 to 4294967295 1 F9 0
01F8 Port 6: Number of MAC error packets 0 to 4294967295 1 F9 0
01FA Port 6: Number of dropped received packets 0 to 4294967295 1 F9 0
01FC Port 6: Number of multicast frames sent 0 to 4294967295 1 F9 0
01FE Port 6: Number of broadcast frames sent 0 to 4294967295 1 F9 0
0200 Port 6: Number of <64 byte fragments with good CRC 0 to 4294967295 1 F9 0
0202 Port 7: Number of bytes received 0 to 4294967295 1 F9 0
0204 Port 7: Number of bytes sent 0 to 4294967295 1 F9 0
0206 Port 7: Number of frames received 0 to 4294967295 1 F9 0
0208 Port 7: Number of frames sent 0 to 4294967295 1 F9 0
020A Port 7: Total bytes received 0 to 4294967295 1 F9 0
020C Port 7: Total frames received 0 to 4294967295 1 F9 0
020E Port 7: Number of broadcast frames received 0 to 4294967295 1 F9 0
0210 Port 7: Number of multicast frames received 0 to 4294967295 1 F9 0
Table 18–1: Modbus memory map (Sheet 7 of 21)
Address Description Range Step Format Default
