CHAPTER 18: MODBUS PROTOCOL MEMORY MAPPING
MULTILINK ML1600 ETHERNET COMMUNICATIONS SWITCH – INSTRUCTION MANUAL 18–11
026E Port 9: Total bytes received 0 to 4294967295 1 F9 0
0270 Port 9: Total frames received 0 to 4294967295 1 F9 0
0272 Port 9: Number of broadcast frames received 0 to 4294967295 1 F9 0
0274 Port 9: Number of multicast frames received 0 to 4294967295 1 F9 0
0276 Port 9: Number of frames with CRC error 0 to 4294967295 1 F9 0
0278 Port 9: Number of oversized frames received 0 to 4294967295 1 F9 0
027A Port 9: Number of bad fragments received (<64 bytes) 0 to 4294967295 1 F9 0
027C Port 9: Number of jabber frames received 0 to 4294967295 1 F9 0
027E Port 9: Number of collisions occurred 0 to 4294967295 1 F9 0
0280 Port 9: Number of late collisions occurred 0 to 4294967295 1 F9 0
0282 Port 9: Number of 64-byte frames received/sent 0 to 4294967295 1 F9 0
0284 Port 9: Number of 65 to 127 byte frames received/sent 0 to 4294967295 1 F9 0
0286 Port 9: Number of 128 to 255 byte frames received/sent 0 to 4294967295 1 F9 0
0288 Port 9: Number of 256 to 511 byte frames received/sent 0 to 4294967295 1 F9 0
028A Port 9: Number of 512 to 1023 byte frames received/sent 0 to 4294967295 1 F9 0
028C Port 9: Number of 1023 to maximum byte frames received/sent 0 to 4294967295 1 F9 0
028E Port 9: Number of MAC error packets 0 to 4294967295 1 F9 0
0290 Port 9: Number of dropped received packets 0 to 4294967295 1 F9 0
0292 Port 9: Number of multicast frames sent 0 to 4294967295 1 F9 0
0294 Port 9: Number of broadcast frames sent 0 to 4294967295 1 F9 0
0296 Port 9: Number of <64 byte fragments with good CRC 0 to 4294967295 1 F9 0
0298 Port 10: Number of bytes received 0 to 4294967295 1 F9 0
029A Port 10: Number of bytes sent 0 to 4294967295 1 F9 0
029C Port 10: Number of frames received 0 to 4294967295 1 F9 0
029E Port 10: Number of frames sent 0 to 4294967295 1 F9 0
02A0 Port 10: Total bytes received 0 to 4294967295 1 F9 0
02A2 Port 10: Total frames received 0 to 4294967295 1 F9 0
02A4 Port 10: Number of broadcast frames received 0 to 4294967295 1 F9 0
02A6 Port 10: Number of multicast frames received 0 to 4294967295 1 F9 0
02A8 Port 10: Number of frames with CRC error 0 to 4294967295 1 F9 0
02AA Port 10: Number of oversized frames received 0 to 4294967295 1 F9 0
02AC Port 10: Number of bad fragments received (<64 bytes) 0 to 4294967295 1 F9 0
02AE Port 10: Number of jabber frames received 0 to 4294967295 1 F9 0
02B0 Port 10: Number of collisions occurred 0 to 4294967295 1 F9 0
02B2 Port 10: Number of late collisions occurred 0 to 4294967295 1 F9 0
02B4 Port 10: Number of 64-byte frames received/sent 0 to 4294967295 1 F9 0
02B6 Port 10: Number of 65 to 127 byte frames received/sent 0 to 4294967295 1 F9 0
02B8 Port 10: Number of 128 to 255 byte frames received/sent 0 to 4294967295 1 F9 0
02BA Port 10: Number of 256 to 511 byte frames received/sent 0 to 4294967295 1 F9 0
02BC Port 10: Number of 512 to 1023 byte frames received/sent 0 to 4294967295 1 F9 0
02BE Port 10: Number of 1023 to maximum byte frames received/sent 0 to 4294967295 1 F9 0
02C0 Port 10: Number of MAC error packets 0 to 4294967295 1 F9 0
02C2 Port 10: Number of dropped received packets 0 to 4294967295 1 F9 0
02C4 Port 10: Number of multicast frames sent 0 to 4294967295 1 F9 0
02C6 Port 10: Number of broadcast frames sent 0 to 4294967295 1 F9 0
02C8 Port 10: Number of <64 byte fragments with good CRC 0 to 4294967295 1 F9 0
Table 18–1: Modbus memory map (Sheet 9 of 21)
Address Description Range Step Format Default
