Troubleshooting

Problems with the S130

Once the message

SHUTDOWN COMPLETED

is displayed, switch the S130 to CE mode by

switching the CE key on the inside of the maintenance panel of the S130 to the position
“Maintenance Mode On”.

The CE mode is indicated by the display CE on the control panel of the S130 (see
page 12f) and in line 23 of the SVPST0 window on the SKP operating terminal (see
page 40).

Select the SVPST0 window on the SKP operating terminal (see page 36).

Press the

key. It switches to CE mode in the Index Frame.

Select the Generation Frame by entering the frame code

and press the

key.

Enter

in the input field

SETUP ITEM =>

to select the SYSTEM FEATURE and press the

key.

The following frame is displayed:

Figure 45: GENERATION FRAME: SYSTEM screen

Enter

in the field

UPDATE =>

to modify the generation. Confirm your input by pressing

the

key.

Enter

for the defective CPU and

for the next available CPU. Confirm your input by

pressing the

key.

Press the

key.

Respond to the question

DO YOU WANT TO SAVE SETUP DATA: ?

in the subsequent frame

with

. Confirm your input by pressing the

key.

ENTER

----- GENERATION FRAME: SYSTEM ----- E02L01F-01Q+013
--- SYSTEM FEATURE ---
MODEL => GS8600 FVC => 60 FMODEL => 8600
TYPE => /40 IVC => 00 IMODEL => 3090
--- INSTALLATION (Y/N) ---
CPU0 => Y CPU1 => Y CPU2 => N CPU3 => N
CPU4 => N CPU5 => N CPU6 => N CPU7 => N
MSU0 => Y MSU1 => Y
CHP0 => Y CHP1 => N CHP2 => Y CHP3 => N
IOPA0=> Y IOPA1=> Y IOPA2=> N IOPA3=> N
IOPA4=> Y IOPA5=> N IOPA6=> N IOPA7=> N

--- MULTI CLUSTER FEATURE ---
DOMAIN SSU CAPACITY => 00000000 (MB)
GSIGP I/O RESET TIME-OUT => 30 (SEC)

UPDATE => N (Y/N) PF3:RETURN PF6:CANCEL PF7:PAGE UP PF8:PAGE DOWN
CL-0 CPU-0 CHP-0 RUN
M CE TEST

LTG TAST

ENTER
