U25339-J-Z126-1-7600 55
Standard processing in SVP mode User frames
Special key functions
Sets operating mode. If a loading function has previously been stored in PROGRAM
LOAD FRAME: DETAIL-1 with the
key, an IPL with the set parameters is
executed.
Switches to PROGRAM LOAD FRAME: BASIC (page 50)
Switches to PROGRAM LOAD FRAME: DETAIL-1 (page 51)
With the exception of the load function, the parameters entered in the subframes are
retained when switching between DETAIL-1 and DETAIL-2-FRAME with the
key.
6.4.3 (ST) STATUS DISPLAY FRAME: CLUSTER
Figure 19: STATUS DISPLAY FRAME: CLUSTER screen
This frame displays information on the current status of the S130 and its individual compo-
nents (Power on/off, online/offline, normal/maintenance state etc.). Unmounted compo-
nents are not displayed. The memory size, operating system mode (BS2000 or VM2000),
and availability of the SKP (
FTOPS2 ENABLE ) are important displays.
Special key functions
Switches to the SSU FRAME (see next page)
ENTER
P9
P3
P9
P9
----- STATUS DISPLAY FRAME: CLUSTER ----- E02L01F
CPU0 (#0) ONL RUN CHBP0 PON
CPU1 (#1) ONL RUN
MSU0 ONL
MSU1 ONL
SPC
SCI
SVP
SYS PON
MCU0
CHP0 ONL
CHP2 ONL
SYSTEM INFORMATION
MEMORY 3 GB
MODE EXA
FTOPS2 ENABLE
*PF8 SSU FRAME
CL-0 CPU-0 CHP-0 RUN
M
FLAG CODE = F6C0C100 00000F00
LTG TAST
P8
