56 U25339-J-Z126-1-7600
User frames Standard processing in SVP mode
Figure 20: STATUS DISPLAY FRAME: SSU screen
This displays information on the status of the connected global storage. Memory size,
battery status, power status, online status, and connect status are displayed.
Special key functions
Switches to the CLUSTER FRAME (see previous page)
----- STATUS DISPLAY FRAME: SSU ----- E02L01F
SS0 (SSU0) 512MB BS
SS1 (SSU1) 512MB BS
SSU0 PON ONL CNCT 512MB BS
SSU1 PON ONL CNCT 512MB BS
*PF7 CLUSTER FRAME
CL-0 CPU-0 CHP-0 RUN
M
ssu0 FLAG CODE = F6C0C100 00000F00
LTG TAST
P7
