1.3 Power Requirements
C141-E145-02EN 1-5
Table 1.1 lists the formatted capacity, number of logical cylinders, number
of heads, and number of sectors of every model for which the CHS mode
has been selected using the BIOS setup utility on the host.
Table 1.1 Specifications (2/2)
Model Capacity No. of Cylinder No. of Heads No. of Sectors
MHR2040AT 8.45 GB 16,383 16 63
MHR2030AT 8.45 GB 16,383 16 63
MHR2020AT 8.45 GB 16,383 16 63
MHR2010AT 8.45 GB 16,383 16 63
1.2.2 Model and product number
Table 1.2 lists the model names and product numbers of the MHR Series.
Table 1.2 Model names and product numbers
Model Name Capacity
(user area)
Mounting screw Order No.
MHR2040AT 40 GB M3, depth 3 CA06062-B042
MHR2030AT 30 GB M3, depth 3 CA06062-B032
MHR2020AT 20 GB M3, depth 3 CA06062-B022
MHR2010AT 10 GB M3, depth 3 CA06062-B012
1.3 Power Requirements
(1) Input Voltage
• + 5 V ± 5 %
(2) Ripple
+5 V
Maximum 100 mV (peak to peak)
Frequency DC to 1 MHz
