FUJITSU MHR2030AT User Manual
Page 15

Contents
C141-E145-02EN
xi
4.6.1 Read/write preamplifier (HDIC) 4-10
4.6.2 Write circuit 4-10
4.6.3 Read circuit 4-12
4.6.4 Digital PLL circuit 4-13
4.7
Servo Control 4-14
4.7.1 Servo control circuit 4-14
4.7.2 Data-surface servo format 4-17
4.7.3 Servo frame format 4-19
4.7.4 Actuator motor control 4-20
4.7.5 Spindle motor control 4-21
CHAPTER 5
Interface..................................................................................... 5-1
5.1
Physical Interface 5-2
5.1.1 Interface signals 5-2
5.1.2 Signal assignment on the connector 5-3
5.2
Logical Interface 5-6
5.2.1 I/O registers 5-7
5.2.2 Command block registers 5-8
5.2.3 Control block registers 5-13
5.3
Host Commands 5-14
5.3.1 Command code and parameters 5-14
5.3.2 Command descriptions 5-18
5.3.3 Error posting 5-104
5.4
Command Protocol 5-106
5.4.1 PIO Data transferring commands from device to host 5-106
5.4.2 PIO Data transferring commands from host to device 5-108
5.4.3 Commands without data transfer 5-110
5.4.4 Other commands 5-112
5.4.5 DMA data transfer commands 5-112
5.5
Ultra DMA Feature Set 5-115
5.5.1 Overview 5-115
5.5.2 Phases of operation 5-116
