Interface
5-48
C141-E145-02EN
At command issuance (I/O registers setting contents)
1F7
H
(CM)
1
1
0
0
0
1
1
0
1F6
H
(DH)
x
x
x
DV
xx
1F5
H
(CH)
1F4
H
(CL)
1F3
H
(SN)
1F2
H
(SC)
1F1
H
(FR)
xx
xx
xx
Sector count/block
xx
After power-on the READ MULTIPLE and WRITE MULTIPLE command
operation are disabled as the default mode.
At command completion (I/O registers contents to be read)
1F7
H
(ST)
Status information
1F6
H
(DH)
x
x
x
DV
xx
1F5
H
(CH)
1F4
H
(CL)
1F3
H
(SN)
1F2
H
(SC)
1F1
H
(ER)
xx
xx
xx
Sector count/block
Error information
(16) SET MAX (F9)
SET MAX Features Register Values
Value
Command
00h
Obsolete
01h
SET MAX SET PASSWORD
02h
SET MAX LOCK
03h
SET MAX UNLOCK
04h
SET MAX FREEZE LOCK
05h - FFh
Reserved
