(39) SET MAX ADDRESS EXT (37H)
• Description
This command limits specifications so that the highest address that can be
accessed by users can be specified only in LBA mode.
The address information specified with this command is set in words 1, 54,
57, 58, 60, 61, and 100 to 103 of the IDENTIFY DEVICE command
response. If read or write processing is executed for an address that is
outside of the new address space, an ID Not Found error occurs.
If the SC register bit is 0 and the value volatile (VV) bit is 1 when this
command is executed, the specified values are maintained after a power-on
reset. If the VV bit is 0 when the command is executed, the specified values
are invalidated during the power-on sequence. If the VV bit is 1, the highest
address value is defined as the last value specified. (If the VV bit is not set to
1, the highest address is the default value.)
After a power-on reset is performed, a host can issue the SET MAX
ADDRESS (EXT) command only once if the VV bit is 1. If the SET MAX
ADDRESS (EXT) command is issued twice or more, an ID Not Found error
occurs.
• Error reporting conditions
− This command is issued twice or more in an operation sequence. (ST =
51h, ER = 10h, ID Not Found)
− The READ NATIVE MAX ADDRESS EXT command (27h) is not
issued immediately before this command (ST = 51h, ER = 04h, Aborted)
is issued.
− This command is issued while LBA = 0 (ST = 51h, ER = 04h, Aborted)
At command issuance (I/O registers setting contents)
1F7
h
(CM) 0 0 1 1 0 1 1 1
1F6
h
(DH) 1 L 1 DV xx
1F5
h
(CH) P
1F5
h
(CH) C
1F4
h
(CL) P
1F4
h
(CL) C
1F3
h
(SN) P
1F3
h
(SN) C
SET MAX LBA (47-40)
SET MAX LBA (23-16)
SET MAX LBA (39-32)
SET MAX LBA (15-8)
SET MAX LBA (31-24)
SET MAX LBA (7-0)
1F2
h
(SC) P xx
1F2
h
(SC) C xx VV
1F1
h
(FR) P
1F1
h
(FR) C
xx
xx
C: Current
P: Previous
