RESTRICTED USE ONLY Fargo Electronics, Inc.
HDP600 High Definition Card Printer/Encoder User Guide (Rev. 2.3) 3-18
Loading the Overlaminate (cont.)
Step Procedure
5 Load the take-up end of the roll just as you loaded the supply end. (Note: When
loaded properly, the overlaminate material should feed underneath from and take-
up from underneath each roll.)
Display B
–
Loading the overlaminate (take-up spool)
