Opening and closing the rack server, 2 opening and closing the rack server – FUJITSU PRIMERGY B120 User Manual
Page 42
Opening and closing the server
Opening and closing the rack server
34
A26361-K646-Z102-1-7619
5.2
Opening and closing the rack server
2
1
Ê
Release the four knurled screws (1) and pull the server carefully out of the rack up to the
stop (2).
1
2
Ê
Press the locking springs on both sides of the server (1) and carefully remove the server from
the rack (2).
