A26361-K646-Z102-1-7619

33

5

Opening and closing the server

!

Please take note of the safety information in the chapter "

Important notes

".

Ê

Switch the server off.

!

Pull the power plug out of the power outlet.

Ê

Disconnect all cables on the rear that are obstructing you.

5.1

Opening and closing the tower server

1

4

2

3

Ê

Unlock the server (1).

Ê

Unscrew the two knurled screws (2).

Ê

Push the side cover approx. 2 cm backwards (3).

Ê

Remove the side cover sidewards (4).

Ê

Closing is performed in the reverse order.
