Locking the tower server, 5 locking the tower server – FUJITSU PRIMERGY B120 User Manual
Page 38
Preparation for use and operation
Locking the tower server
30
A26361-K646-Z102-1-7619
4.5
Locking the tower server
Fitting the hard disk cover
2
3
4
5
1
Ê
If the server is locked, unlock it (1).
Ê
Slide the drive cover completely upwards (2).
Ê
Fit the hard disk cover (3 + 4).
Ê
Slide the drive cover downwards (5).
