Installation
Prepare the keyboard
20
A26361-K646-Z102-1-7619
1
2
Ê
Plug the power cable of the server into the server (1) and into a free electrical outlet of the
multi-outlet assembly in the rack (2) (see technical manual for rack).
Guide the cable through the cable routings of the rack.
3.6
Prepare the keyboard
Ê
Plug the appropriate connector of the keyboard cable into the socket on the underside of the
keyboard as shown in the illustration above.
