Page 47

MK SG-2
Revision 11/01, Effective Date November 13, 2001
Page 47
EXPLODED VIEW AND PARTS LIST
Item
Description
Qty
Part #
H
Assembly, Throttle Honda
-
-
H1
Screw, 10-24 X 1/2 Pan Head Phillips Cap
2
151744
H2
Nut, 10-24 Clip
2
155407
H3
Assembly, Throttle Head
1
155406
H4
Cable, Throttle, Honda
1
154158
J
Assembly, Depth Control
-
-
-
Subassembly, Depth Control Wheel
1
155457
J1
Wheel, Depth Control
1
158574
J2
Screw, 3/8-16 X 1/2 Socket Head Set
1
153710
J3
Knob, 1” Ball
1
158519
J4
Screw, 1/2 X 3/4 Socket Head Shoulder, w/ 3/8-16 X 5/8 Thread
1
156177
-
Subassembly, Depth Control Tube
1
155460
J5
Tube, Depth Control
1
155049
J6
Nut, 3/8-16 Nylock Hex
1
152505
J7
Screw, 3/8-16 X 2 Hex Head Cap
1
153485
J8
Bearing, Flange, w/ zerk fitting
1
155151
J9
Screw, 3/8-16 X 1–1/4 Hex Head Cap
2
150774
J10
Washer, 3/8 SAE Flat
1
150923
J11
Nut, 3/8-16 Nylock Hex
2
152505
J12
Spacer, 1.5” Depth Control
1
155161
J13
Screw, 15” Depth Control
1
158521
K
Assembly, Depth Lock
-
n/a
K1
Lock, 8-7/8 Depth Control
1
157846
K2
Knob, Depth Lock
1
155845
K3
Thrust Washer
1
155238
K4
Nut, 3/8-16 Nylock Hex
1
152505
L
Assembly, Quick Lift and Lowering Lever
-
n/a
L1
Lever
1
158102
L2
Knob, 2” Ball
1
158519
L3
Screw, 3/8-24 x 1 Hex Head Cap
1
157803
L4
Washer, 3/8 SAE Flat
1
150923
L5
Washer, 3/8 Split Lock
1
150925
L6
Pivot, Shaft
1
158288
L7
Screw, 1/2-13 x 1–1/4 Hex Head Cap
1
153532
L8
Washer, 1/2 Split Lock
1
153524
L9
Washer, 1/2 SAE Flat
1
150924
