MAINTENANCE AND TROUBLESHOOTING
10. Cutting Drum Change-out:
Disconnect the tool before servicing and when changing accessories, such as blades, bits,
cutters, and the like.
(A)
Remove the Shaft Cover, Rear
Retaining Bolt and loosen the
Front Retaining Bolt using 9/16
wrenches and/or sockets
Remove Rear
Retaining Bolt
Loosen Front
Retaining Bolt
(C)
Using a 15/16-inch socket,
loosen the Outer Shaft,
Retaining Nut
(B)
Remove the Shaft, Retaining
Nut Cover from the Belt Guard
to expose the Shaft, Retaining
Nuts
Shaft,
Retaining Nuts
Retaining
Nut, Cover
Turn clockwise
to loosen
(F)
Repeat Step C through E for the
Inner Shaft, Retaining Nut
(E)
Remove the Outer Shaft,
Retaining Nut using your Middle
Finger as shown
(D)
Place an Index Finger on the
end of the Cutting Drum, Shaft
Place Index Finger
on Shaft end
Rotate clockwise
to remove
Remove
Inner Nut
Hold Cutting
Drum
Remove
Shaft
(F)
Remove the Cutting
Drum and Shaft
(G)
Reconfigure the Cutting Drum
as needed
Reconfigure Cutting Drum
(H)
Install the Cutting Drum into the
SG-2; align the Cutting Drum with
the Shaft-side Bearing and install
the Cutting Drum, Shaft
Hold Cutting
Drum
Install
Shaft
