Maintenance and troubleshooting – HONDA MK SG-2 User Manual
Page 33

MK SG-2
Revision 11/01, Effective Date November 13, 2001
Page 33
MAINTENANCE AND TROUBLESHOOTING
(J)
Install the Shaft, Inner Retaining
Nut
(I)
Verify the Cutting Drum and
Shaft are fully installed and
seated
Cutting Drum
Seated
Shaft
Seated
Rotate counter-
clockwise to install
(M)
Install the Shaft, Outer Retaining
Nut
(L)
Obtain the Shaft, Outer
Retaining Nut
(K)
Using a 15/16-inch socket tighten
the Shaft, Inner Retaining Nut
Rotate counter-
clockwise to tighten
Outer
Retaining Nut
Rotate counter-
clockwise to install
(N)
Using a 15/16-inch socket tighten
the Shaft, Outer Retaining Nut
Rotate counter-
clockwise to tighten
(P)
Pivot the Shaft Guard Cover into
position and install the Rear
Retaining Bolt
(O)
Install the Shaft, Retaining Nut
Cover onto the Belt Guard
Retaining
Nut, Cover
Install Rear
Retaining Bolt
Shaft Cover
(J)
Tighten the Shaft Guard Cover
Retaining Bolts using 9/16
wrenches and/or sockets
Tighten the
Retaining Bolts
