MK SG-2 Revision 11/01, Effective Date November 13, 2001 Page 34
MAINTENANCE AND TROUBLESHOOTING
11. Reconfigure the Cutting Drum:
(A)
Remove the Cutting Drum from
the SG-2 (See Cutting Drum
Change-out, Section 6)
Remove Cutting Drum
(B)
Place the Cutting Drum on end
and remove the 3 Retaining
Screws using a 7/16-inch wrench
Turn clockwise
to tighten
(C)
Remove the Retaining Ring from
the Cutting Drum
Retaining
Ring
(D)
If present, remove the three Flat
Washer Spacers
Retaining
Screw
Flat Washer
Spacer
(E)
Place the Retaining Ring and
the 3 Flat Washer Spacers in a
secure location
Retaining
Ring
Flat Washer
Spacer
(F)
Pull the Cutting Disc Shafts and
remove the Cutting Discs and
Disc Spacers
Cutting
Disc
Disc
Spacer
(G)
Assemble the Cutting Drum
using Cutting Discs and Disc
Spacers (See Cutting Drum
Configuration, Page 21)
Cutting
Disc Shaft
(H)
Continue with Step B until the
Cutting Drum assembly is
complete
Complete
Assembly
Cutting
Disc
Disc
Spacer
(I)
Place the Cutting Drum on the
closed end, with the open end
facing upward
Open
End
Rotate
Upright
