MAINTENANCE AND TROUBLESHOOTING
9. Engine Air Filter Inspection Cleaning and Replacement:
(D)
Clean the Foam Filter with warm
soapy water – allow to air dry
(C)
Separate the outer Foam Filter
from the inner Paper Filter
(B)
Remove the Dual Air Filter
(A)
Remove the Air Filter Cover
(F)
Inspect Paper Filter, tap on hard
surface to clean or use 30psi air
(direct air inside filter to clean)
(E)
Dip the Foam Filter in clean
engine oil – Squeeze out
excess oil
Submerge
with Oil
Tap to Clean
or use
compressed air
Turn counter-
clockwise to
loosen
Turn counter-
clockwise to
loosen
Foam Filter
Paper Filter
Clean Foam Filter
Paper Filter
Dual Air Filter
(G)
Remove the 3 Cyclone Filter
Assembly retaining screws
(I)
Separate the Air Guide from the
Cyclone Housing and clean
using soap and water
(H)
Remove the Cyclone Filter
Assembly from the Air Filter Cover
Turn counter-
clockwise to
loosen
Retaining Screw
Cyclone Filter
Assembly
Cyclone Filter
Assembly
Air Guide
Cyclone Housing
Air Filter Cover
