SETUP, STARTUP, ADJUSTMENT, OPERATION and SHUTDOWN
2. Basic Grinding Techniques:
NOTE: The Height Adjustment Hand-wheel will adjust the depth (up or down) of the Cutting Drum by 1/16 of
an inch per turn.
I. Leveling a Surface:
A) Configure the Cutting Drum for Grooving (See Section 3)
B) Locate the lowest spot and highest spot on the surface
C) Adjust the height of the Cutting Drum to remove approximately 1/16 of an inch from the High spot
D) Set the Vibration Lock
E) Move the SG-2 in a smooth forward motion.
F) When the Cutting Discs are no longer contacting the surface, return the SG-2 to the starting position
G) Repeat Steps A through E until the Surface is level (See Figure 1)
II. Cutting / Grooving a Surface:
A) Configure the Cutting Drum for Grooving (See Section 3)
B) Adjust the Cutting Drum Depth until the SG-2 is cutting grooves approximately 1/8 of an inch
C) Move the SG-2 in a smooth forward motion
D) Should the Cutting Discs loose contact with the surface, repeat Step B and continue forward motion
E) Repeat Steps A through D until the desired number of grooves are cut (See Figure 2)
Low Point
Direction of movement
Set 1/16 – inch
below the surface
High Point
Figure 1
Set 1/8 – inch
below the surface
Maintain set
cutting depth
Direction of movement
Figure 2
