MK SG-2 Revision 11/01, Effective Date November 13, 2001 Page 14
UNPACKING, TRANSPORT and ASSEMBLY
3. Filling Oil Reservoir:
NOTE: SAE 10W-30 is recommended for general use in temperatures of – 4ºF (20ºC) and above. If you
are operating outside of this range, consult the chart in this manual.
Engine Oil Capacity is 1.16 US qt (1.1l).
(C)
Fill Oil Reservoir
(B)
Remove Dipstick
(A)
Rotate the SG-2 upright
Dipstick
Turn counter-
clockwise to
loosen
(J)
Tighten the Shaft Guard Cover
Retaining Bolts using 9/16
wrenches and/or sockets
(I)
Pivot the Shaft Guard Cover into
position and install the Rear
Retaining Bolt
(H)
Install the Shaft, Retaining Nut
Cover onto the Belt Guard
(G)
Using a 15/16-inch socket tighten
the Shaft, Outer Retaining Nut
Rotate counter-
clockwise to tighten
Retaining
Nut, Cover
Tighten the
Retaining Bolts
Install Rear
Retaining Bolt
Shaft Cover
Rotate
Upright
Fill through
Reservoir fill hole
