Wall-mounted Bracket
1.Wall-mounted Structural Accessories
1712mm 30 ×30 aluminum bracket× 4
Overall appearance diagram of wall-mounted structure (size: mm):
1527mm 30×30 aluminum
bracket × 8
L-shaped 30 bracket iron
corner connector × 48
M6 × (14) hexagon socket head
cap screw× 72PCS
M6 T-Nut ×72
Slotted bracket connector ×8
M4 Slotted profile connector fixing screws ×32
