Brother FAX 3750 User Manual
Page 99
87
O P T I O N A L A C C E S S O R I E S ( F O R F A X 2 7 5 0 O N L Y )
3
To install the memory board onto the main controller board, use the
attached spacer and plug it into the connectors on the left of the main
controller board.
Spacer
Connector
Connector
Memory
Board
Main
Controller
Board
WARNING
■
Hold the edge of the memory board. Do not touch the surface of the board.
■
Make sure the memory board is securely seated in the main controller board.
4
Reinstall the rear cover.
5
Reconnect the interface cable.
6
Plug the power cord into the AC outlet.
