6.3.4 Power Connector (CN7)
PIN NO.
DESCRIPTION
1 +19V
2 GND
Table 6-19: Power Connector (CN7) Pinouts
6.3.5 SD Card Slot (J1)
PIN NO.
DESCRIPTION
1 DATA3
2 CMD
3 GND
4 VCC
5 CLK
6 GND
7 DATA0
8 DATA1
9 DATA2
10 Card
detect
11 GND
12 Wire
protection
Table 6-20: SD Card Slot (J1) Pinouts
6.3.6 USB Host Connector (CN8)
PIN NO.
DESCRIPTION
1 GND
2 DP2
3 DM2
4 VUSB2
Table 6-21: USB Host Connector (CN8) Pinouts
