ICECARE-07 Mobile Field Assistant
Page 30
Figure 3-19: USB Device Connection
Step 3: Insert the device connector . Once aligned, gently insert the USB device
connector into the on-board connector. Step 0:
3.9 Using the Docking Cradle (Optional)
The docking cradle allows to charge the battery packs of the ICECARE-07 and extends its
capabilities, including an RS-232 serial port, a USB host connector and a 10/100 Mbps
Ethernet connector.
3.9.1 Installing the ICECARE-07 to the Docking Cradle
To install the ICECARE-07 to the docking cradle, simply place the ICECARE-07 to the
docking cradle (Figure 3-20).
